GDC2030md
|
GDC2540md
|
GDC3540md
|
|
Worktable
|
Worktable size
|
2000×3000mm
|
2500×4000mm
|
3500×4000mm
|
|
Max.mass on table
|
7000kg/m2
|
7000kg/m2
|
7000kg/m2
|
|
T-slot
|
22×6mm×N
|
22×8mm×N
|
36×8mm×N
|
|
Machining range
|
Gantry travel(X-axis)
|
No tool magazine
|
3000mm
|
4000mm
|
4000mm
|
|
tool magazine
|
2750mm
|
3750mm
|
3750mm
|
|
Saddle travel(Y-axis)
|
2000mm
|
2500mm
|
3500mm
|
|
Ram travel (Z-axis)
|
500mm
|
500mm
|
500mm
|
|
Distance of spindle nose to table surface
|
Max.
|
650mm
|
650mm
|
900mm
|
|
Min.
|
150mm
|
150mm
|
400mm
|
|
Spindle
|
Hole in spindle(7:24)
|
BT50
|
BT50
|
BT50
|
|
Range of spindle speed
|
40-4500r/min
|
40-4500r/min
|
40-4500r/min
|
|
Max.spindle torque
|
385/528(optional
565/770)
N.m
|
385/526(optional
565/770)
N.m
|
385/526(optional
565/770)
N.m
|
|
Max.axial carrying resisting force
|
15000N
|
15000N
|
15000N
|
|
Power of main motor
|
15/20.5×2
(optional
22/30×2)kW
|
15/20.5×2
(optional
22/30×2)kW
|
15/20.5×2
(optional
22/30×2)kW
|
|
Max.drilling diameter
|
φ50mm
|
φ50mm
|
φ50mm
|
|
Max.milling tool diameter
|
φ125mm
|
φ1250mm
|
φ125mm
|
|
Max,tapping diameter
|
Cast iron
|
M30mm
|
M30mm
|
M30mm
|
|
Carbon steel
|
M24mm
|
M24mm
|
M24mm
|
|
Feed
|
Cutting feedrate
|
1-5000mm/min
|
1-5000mm/min
|
1-5000mm/min
|
|
Rapid traverse
|
X-axis
|
10m/min
|
10m/min
|
10m/min
|
|
Y-axis
|
10m/min
|
8m/min
|
8m/min
|
|
Z-axis
|
10m/min
|
10m/min
|
10m/min
|
|
Positioning accuracy
|
JB/T8771.4-1998
|
X-axis
|
0.030mm
|
0.035mm
|
0.035mm
|
|
Y-axis
|
0.025mm
|
0.030mm
|
0.035mm
|
|
Z-axis
|
0.012mm
|
0.012mm
|
0.012mm
|
|
Executing standard(JISB6330)
|
X-axis
|
±0.005/300mm
|
±0.005/300mm
|
±0.005/300mm
|
|
Y-axis
|
±0.005/300mm
|
±0.005/300mm
|
±0.005/300mm
|
|
Z-axis
|
±0.005/300mm
|
±0.005/300mm
|
±0.005/300mm
|
|
Repeatability
|
JB/T8771.4-1998
|
X-axis
|
0.018mm
|
0.022mm
|
0.022mm
|
|
Y-axis
|
0.014mm
|
0.018mm
|
0.022mm
|
|
Z-axis
|
0.008mm
|
0.008mm
|
0.008mm
|
|
Executing standard(JISB6330)
|
X-axis
|
±0.003mm
|
±0.003mm
|
±0.003mm
|
|
Y-axis
|
±0.003mm
|
±0.003mm
|
±0.003mm
|
|
Z-axis
|
±0.003mm
|
±0.003mm
|
±0.003mm
|
|
weight of machine
|
28400kg
|
33900kg
|
42500kg
|
|
CNC system
|
SIEMENS840D
|
SIEMENS840D
|
SIEMENS840D
|
|
Electrical total capacity
|
98KVA
|
98KVA
|
98KVA
|
