HTC63
|
HTC80
|
HTC8030b
|
|
Chuck diameter
|
φ400mm
|
φ500mm
|
φ500mm
|
|
Max.swing over bed
|
φ810mm
|
φ1000mm
|
φ980mm
|
|
Max.swing over carriage
|
φ600mm
|
φ800
|
φ700
|
|
Max.range of disc typework
|
|
|
φ800×300mm
|
|
Max.travel of X/Z-axis
|
|
|
535/1100mm
|
|
Max.cutting length
|
1000mm
|
1500mm
|
3000mm
|
4000mm
|
1000mm
|
1500mm
|
3000mm
|
4000mm
|
|
|
Spindle bore diameter
|
φ100(φ125)mm
|
φ125(φ140)mm
|
φ140mm
|
|
Range of spindle speed
|
50-1800r/min
|
50-1600r/min
|
50-1400r/min
|
|
Spindle nose
|
A2-8(A2-11)
|
A2-11(A2-15)
|
A2-15
|
|
Diameter of tailstock quill
|
φ160mm
|
φ160mm
|
|
|
Travel of tailstock quill
|
120mm
|
120mm
|
|
|
Taper of tailstock quill
|
Morse No.5
|
Morse No.5
|
|
|
Motor torque for X/Z axis
|
22/30Nm
|
22/30Nm
|
22/30Nm
|
|
Rapid speed (X/Z axis)
|
10/12
m/min
|
10/12
m/min
|
10/10
m/min
|
10/16
m/min
|
10/12
m/min
|
10/12
m/min
|
10/10
m/min
|
10/16
m/min
|
8/10m/min
|
|
No.of tool stations
|
12Public spaces
|
12Public spaces
|
8Public spaces
|
|
Size of tool shank
|
32×32mm
|
32×32mm
|
32×32mm
|
|
Diameter of tool hole
|
φ50mm
|
φ50mm
|
φ80mm
|
|
Positioning accuracy of tool turret
|
±4"
|
±4"
|
|
|
Repeatability of tool turret
|
±1.6"
|
±1.6"
|
0.005"
|
|
Workpiece accuracy
|
IT6
|
IT6
|
IT6
|
|
Roughness
|
Ra1.6
|
Ra1.6
|
Ra1.6
|
|
Nain motor power
|
30/37mm
|
37/45mm
|
37/45mm
|
|
Posi-
tioning accuracy
|
x-axis
|
0.010mm
|
0.010mm
|
0.010mm
|
0.010mm
|
0.010mm
|
0.010mm
|
0.010mm
|
0.010mm
|
0.01mm
|
|
Z-axis
|
0.016mm
|
0.025mm
|
0.038mm
|
0.040mm
|
0.016mm
|
0.025mm
|
0.038mm
|
0.040mm
|
0.016mm
|
|
repea-tability
|
X-axis
|
0.006mm
|
0.006mm
|
0.006mm
|
0.006mm
|
0.006mm
|
0.006mm
|
0.006mm
|
0.006mm
|
0.007mm
|
|
Z-axis
|
0.008mm
|
0.012mm
|
0.025mm
|
0.025mm
|
0.008mm
|
0.012mm
|
0.025mm
|
0.025mm
|
0.010mm
|
|
Overall dimensions
(L×W×H)
|
4650×2600×2640mm
5190×2600×2640mm
6740×2600×2640mm
7690×2600×2640mm
|
4650×2600×2640mm
5190×2600×2640mm
6740×2600×2640mm
7690×2600×2640mm
|
4650×2600×2640mm
|
|
Machine weight(net weight)
|
14000kg
|
16000kg
|
22000kg
|
26000kg
|
15000kg
|
17000kg
|
23000kg
|
27000kg
|
14000kg
|
