STC4540vbs系列汽车成套机床 |
| |
|
| >> STC4540vbs系列Product Preview Keys：
Hits：4362 |
This lathe is special purpose machine for machining front & rear brake shoe used on automobile industry. Features. Single spindle, symmetrical-double-turrets and line-up tooling are available. Tool bolders with high rigidity are made by ourselves according to actual situation of workpiece. All key compinents are imported form foreign well-known builders so that high reliability, big torque and high rigidity can be achieved. Fanuc 0i-Mate, AC main drive and AC feed servo motor are adopted. Special purpose clampers are available for clamping two workpieces simultaneously. With aid of double-turret structure, end surface and circular surface of workpiece can be machined at one time. |
|
| >> STC4540vbs系列Technical parameters |
|
Cutting Capacity
|
Max. Swing over Bed
|
450mm
|
|
Max. Turning Diameter
|
450mm
|
|
Max. Turning Height
|
-
|
|
Spindle
|
Speed Range
|
100-800r/min
|
|
Chuck diameter
|
Special fixtures
|
|
Spindle Nose
|
A211
|
|
Spindle Bearing diameter(front)
|
180mm
|
|
Spindle Max. torque
|
784Nm
|
|
X/Z Axis
|
Stroke of X Axis
|
200mm
|
|
Stroke of Z Axis
|
400mm
|
|
Rapid Speed of X Axis
|
8m/min
|
|
Rapid Speed of Z Axis
|
8m/min
|
|
Accuracy
|
Precision Machining
|
IT6-IT7mm
|
|
X/Z axis positioning accuracy
|
0.025/0.030mm
|
|
X/Z axis repetitive positioning accuracy
|
0.0075/0.015mm
|
|
Tooling
|
Mode of Tool Post
|
Two-carrier knife row
|
|
Size of Shank External cutting tool
|
35×25mm
|
|
Boring tool
|
-
|
|
Power Motors
|
Main Motor (Nomina/30min)
|
22/26kW
|
|
Servo Motor of X Axis
|
2-3kW
|
|
Servo Motor of Z Axis
|
2-4kW
|
|
Motor of Cooling Pump
|
0.75kW
|
|
Overall Dimensions
|
L
|
2600mm
|
|
D
|
2423mm
|
|
H
|
2614mm
|
|
Net Weight
|
12000kg
|
|
