GMB1016
|
GMB1020
|
GMB1225
|
GMB1230
|
|
Workstable
|
Worktable size
|
1000×1600mm
|
1000×2000mm
|
1250×2500mm
|
1250×3000
|
|
Distance between two columns
|
1250mm
|
1250mm
|
1450mm
|
1450mm
|
|
Max. load capacity
|
3000kg
|
3500kg
|
5000kg
|
6000kg
|
|
T-slot
|
22×7mm×N
|
22×7mm×N
|
22×7mm×N
|
22×7mm×N
|
|
Machining range
|
Worktable travel (X-axis)
|
1600mm
|
2000mm
|
2500mm
|
3000mm
|
|
Saddle travel (Y-axis)
|
1000mm
|
1000mm
|
1250mm
|
1250mm
|
|
Spindle box travel (Z-axis)
|
600mm
|
600mm
|
750mm
|
750mm
|
|
Distance from spindle nose to table surface
|
Max.
|
800mm
|
800mm
|
950mm
|
950mm
|
|
Min.
|
200mm
|
200mm
|
200mm
|
200mm
|
|
Spindle
|
Spindle taper(7:24)
|
BT50
|
BT50
|
BT50
|
BT50
|
|
Spindle speed range
|
40-6000r/min
|
40-6000r/min
|
40-6000r/min
|
40-6000r/min
|
|
Max. spindle torque
|
114/152
N.m
|
117/156
N.m
|
114/52
N.m
|
117/156
N.m
|
456/611
N.m
|
468/560
N.m
|
456/611
N.m
|
468/560
N.m
|
|
Spindle motor power
|
12/16kW
|
18.5/22
kW
|
12/16kW
|
18.5/22
N.m
|
12/16kW
|
18.5/22
kW
|
12/16kW
|
18.5/22
kW
|
|
Feed
|
Cutting feed speed range
|
1-10000mm/min
|
1-10000mm/min
|
1-10000mm/min
|
1-10000mm/min
|
|
Rapid travel
|
X-axis
|
20m/min
|
20m/min
|
20m/min
|
20m/min
|
|
Y-axis
|
20m/min
|
20m/min
|
20m/min
|
20m/min
|
|
Z-axis
|
16m/min
|
16m/min
|
16m/min
|
16m/min
|
|
Tool magazine
|
Max. tool length
|
300mm
|
300mm
|
300mm
|
300mm
|
|
Type
|
Disk, chain
|
Disk, chain
|
Disk, chain
|
Disk, chain
|
|
Capacity
|
Disk20、Chain32
|
Disk20、Chain32
|
Disk20、Chain32
|
Disk20、Chain32
|
|
Max. tool diameter Full
|
φ125mm
|
φ125mm
|
φ125mm
|
φ125mm
|
|
Adjacent socket empty
|
φ225mm
|
φ225mm
|
φ225mm
|
φ225mm
|
|
Tool changing time (tip to tip)
|
6s
|
6s
|
6s
|
6s
|
|
Max. tool weight
|
20kg
|
20kg
|
20kg
|
20kg
|
|
Positioning accuracy
|
Executing national standard JB/T8771.4-1998
|
X-axis
|
0.025(0.015
Bring Grating）mm
|
0.025(0.015
Bring Grating）mm
|
0.030(0.020
Bring Grating）mm
|
0.030(0.020
Bring Grating）mm
|
|
Y-axis
|
0.020(0.010
Bring Grating）mm
|
0.020(0.010
Bring Grating）
mm
|
0.020(0.010
Bring Grating）
mm
|
0.020(0.010
Bring Grating）mm
|
|
Z-axis
|
0.015(0.010
Bring Grating）mm
|
0.015(0.010
Bring Grating）
mm
|
0.015(0.010
Bring Grating）
mm
|
0.015(0.010
Bring Grating）
mm
|
|
According to JISB6330 standard
|
X-axis
|
±0.005/300
(±0.003
Bring Grating）mm
|
±0.005/300
(±0.003/300
Bring Grating）mm
|
±0.005/300
(±0.003/300
Bring Grating
）mm
|
±0.005/300
(±0.003/300
Bring Grating）mm
|
|
Y-axis
|
|
Z-axis
|
|
Repeatability
|
Executing national standard JB/T8771.4-1998
|
X-axis
|
0.014(0.010
Bring Grating）
mm
|
0.014(0.010
Bring Grating）mm
|
0.018(0.012
Bring Grating）
mm
|
0.018(.012
Bring Grating）mm
|
|
Y-axis
|
0.012(0.006
Bring Grating）
mm
|
0.012(0.006
Bring Grating）
mm
|
0.012(0.006
Bring Grating）
mm
|
0.012(0.006
Bring Grating）mm
|
|
Z-axis
|
0.010(0.006
Bring Grating）
mm
|
0.010(0.006
Bring Grating）
mm
|
0.010(0.006
Bring Grating）
mm
|
0.010(0.006
Bring Grating）mm
|
|
According to JISB6330 standard
|
X-axis
|
±0.003(±0.002
Bring Grating）mm
|
±0.003(±0.002
Bring Grating）mm
|
±0.003(±0.002
Bring Grating）
mm
|
±0.003(±0.002
Bring Grating）mm
|
|
Y-axis
|
|
Z-axis
|
|
Weight of machine
|
22000kg
|
26000kg
|
31000kg
|
33000kg
|
|
Electric total capacity
|
56KVA
|
61KVA
|
56KVA
|
61KVA
|
59KVA
|
64kVA
|
59KVA
|
64KVA
|
|
CNC system
|
Siemens
802D
|
FANUC
0i
|
Siemens
802D
|
FANUC
0i
|
Siemens
802D
|
FANUC
0i
|
Siemens
802D
|
FANUC
0i
|
