CAK1635v
|
CAK3275v
|
CAK3675v
|
CAK3635v
|
CAK40100v
|
CAK40100vl
|
|
Max. Swing over bed
|
φ160mm
|
φ320mm
|
φ360mm
|
φ360mm
|
φ400mm
|
φ400mm
|
|
Max. Swing over slide
|
φ140mm
|
φ180mm
|
φ180mm
|
φ180mm
|
φ200mm
|
φ200mm
|
|
Max. Cutting diameter over slide
|
φ140mm
|
φ180mm
|
φ180mm
|
φ180mm
|
φ200mm
|
φ200mm
|
|
Max. turning Length
|
260mm
|
Fourth Position650mm
six Position580mm
|
Fourth Position650mm
six Position580mm
|
Fourth Position240mm
|
Fourth Position850mm
six Position750mm
|
Fourth Position850mm
six Position750mm
|
|
Spindle bore
|
φ43mm
|
φ53mm
|
φ53mm
|
φ53mm
|
φ53mm
|
φ53mm
|
|
Spindle nose
|
A2-4
|
A2-6
|
A2-6
|
A2-6
|
A1-6
|
A1-6
|
|
Main motor power(change frequency)
|
4kW
|
5.5kW
|
5.5kW
|
5.5kW
|
5.5kW
|
7.5kW
|
|
Spindle speed
|
500-5000
(Cards hand4000)
r/min
|
200-3000
(Cards hand2000)
r/min
|
200-3000
(Cards hand2000)
r/min
|
200-3000
(Cards hand2000)r/min
|
150-2000ManualⅢ
Frequency stall +
Ⅰ150-520
Ⅱ440-1150
Ⅲ770-2000
|
150-2400(Cards hand2000)r/min
|
|
Diameter of tailstock quill
|
Taiwan matching manual or hydraulic tail
|
φ60mm
|
φ60mm
|
Taiwan matching manual or hydraulic tail
|
φ60mm
|
φ60mm
|
|
Travel of tailstock quill
|
140mm
|
140mm
|
140mm
|
140mm
|
|
Taper of tailstock quill
|
Morse.No4
|
Morse.No4
|
Morse.No4
|
Morse.No4
|
|
Max. travel X axis
|
120mm
|
220mm
|
220mm
|
220mm
|
220mm
|
220mm
|
|
Max. travel Z axis
|
260mm
|
660mm
|
660mm
|
260mm
|
1000mm
|
1000mm
|
|
Tool post rapid traverse (X/Z axis)
|
6/12m/min
|
6/12m/min
|
3.8/7.8m/min
|
3.8/7.8m/min
|
3.8/7.8m/min
|
3.8/7.6m/min
|
|
No. Of tool stations
|
4
|
4
|
4
|
4
|
4
|
4
|
|
Size of tool shank
|
16×16mm
|
20×20mm
|
20×20mm
|
20×20mm
|
20×20mm
|
20×20mm
|
|
Repeatability of X/Z axis
|
0.007/0.008
|
0.007/0.01
|
0.007/0.001
|
0.007/0.01
|
0.007/0.01
|
0.007/0.01
|
|
Work accuracy
|
IT6
|
IT6-IT7
|
IT6-IT7
|
IT6-IT7
|
IT6-IT7
|
IT6-IT7
|
|
Overall dimensions (L×W×H)
|
1780×1230
×1760mm
|
2190×1400
×1610mm
|
2180×1230
×1700mm
|
1780×1230
×1700mm
|
2490×1360
×1510mm
|
2490×1360
×1510mm
|
|
Net/gross weight
|
1450/1690kg
|
1810/2060kg
|
1800/2010kg
|
1555/1790kg
|
1990/2290kg
|
1990/2290kg
|
|
Packing box dimensions (L×W×H)
|
2150×1660
×2050mm
|
2520×1660
×2050mm
|
2520×1660
×2050mm
|
2150×1660
×2050mm
|
2770×1660
×2050mm
|
2770×1660
2050mm
|
