SUC6036连杆小孔组合机系列专用数控机床 |
| |
|
| >> SUC6036连杆小孔组合机系列Product Preview Keys：
Hits：873 |
Machine utilizes dynamic balancing principle, through computer measurement control system to find out the central principal axis of inertia (normally called mass central axis) of the crankshaft roughcast and machine center holes on this axis. Mass centering machine can effectively reduce the initial imbalance of the crankshaft machined, thus improve the final balancing accuracy and efficiency of the crankshaft. Reducing initial imbalance is very important to crankshafts with balancing clump weight. |
|
| >> SUC6036连杆小孔组合机系列Technical parameters |
|
Loading height
|
1200mm
|
|
Max.travel of ciamping device oil tank
|
20mm
|
|
Max.travel of slide(CNC feed)
|
400mm
|
|
Drilling spindle speed (frequency adjustable)
|
800-1200rpm
|
|
Boring spindle speed (frequency adjustable)
|
1000-1500rpm
|
|
T4SP125CNC rotor disc
|
±3"-5"
|
|
Automatic lubrication system
|
8times per shift
|
|
High valtage,large flow capacity cooling system(intemal)
|
180L/min
|
|
|
2.5-3Mpa
|
|
Adjustment volume of imported inching tools
|
0.01mm
|
|
Connecting rod small hole to be machined
|
φ44.5mm
|
|
Connecting rod specification to be machined
|
195mm
|
|
Machine power
|
90kW
|
|
Machine Dimension
|
6000×4000×2800mm
|
|
Machine weight
|
20000kg
|
|
